6.5mm GaugeTrack

These track panels are designed to fit Peco code 100 rail.



Ideal for eith Z gauge, or Nm(N scale metre gauge) or HOf
recommended for indoor use only, as plastic is not fully water proof

Link to :

           6.5mm gauge wagon turntables

       >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>  back to Track Menu page

Description



code 100 rail version





code 75 rail version

Template


curve-lh-junction-inner

6.5mm gauge, straight track on inside , road curves to left. use code 100 rail

curve-lh-junction-inner-75

6.5mm gauge, straight track on inside , road curves to left. use code 75 rail
Print off template



curve-lh-junction-outer

6.5mm gauge, straight track on outside , road curves to left. use code 100 rail
curve-lh-junction-outer-75

6.5mm gauge, straight track on outside , road curves to left. use code 75 rail
Print off template

curve-rh-junction-inner

6.5mm gauge, straight track on inside , road curves to right. use code 100 rail
curve-rh-junction-inner-75

6.5mm gauge, straight track on inside , road curves to right. use code 75 rail
Print off template

curve-rh-junction-outer

6.5mm gauge, straight track on outside , road curves to right. use code 100 rail
curve-rh-junction-outer-75

6.5mm gauge, straight track on outside , road curves to right. use code 75 rail
Print off template

straight-lh-curve-inner-145r

6.5mm gauge rail/road straight section with curved track 145mm radius to left inside of curve. fit code 100 rail
straight-lh-curve-inner-145r-75

6.5mm gauge rail/road straight section with curved track 145mm radius to left inside of curve. fit code 75 rail
Print off template

straight-lh-curve-outer-145r

6.5mm gauge rail/road straight section with curved track 145mm radius to left outside of curve. fit code 100 rail
straight-lh-curve-outer-145r-75

6.5mm gauge rail/road straight section with curved track 145mm radius to left outside of curve. fit code 75 rail
Print off template

straight-rh-curve-inner-145r

6.5mm gauge rail/road straight section with curved track 145mm radius to right inside of curve. fit code 100 rail
straight-rh-curve-inner-145r-75

6.5mm gauge rail/road straight section with curved track 145mm radius to right inside of curve. fit code 75 rail
Print off template

straight-rh-curve-outer-145r

6.5mm gauge rail/road straight section with curved track 145mm radius to right outside of curve. fit code 100 rail
straight-rh-curve-outer-145r-75

6.5mm gauge rail/road straight section with curved track 145mm radius to right outside of curve. fit code 75 rail
Print off template

curve-tram-road-outer-145r

6.5mm gauge, 145mm radius, 45degree, curved inset track on road section 40mm wide, and track on outside of curve. fits code 100 rail(OO/HO)
curve-tram-road-outer-145r-75

6.5mm gauge, 145mm radius, 45degree, curved inset track on road section 40mm wide, and track on outside of curve. fits code 75 rail
Print off template

curve-tram-road-inner-145r

6.5mm gauge, 145mm radius,45degree curved road/rail section with track on inside of curve. fits code 100 rail
curve-tram-road-inner-145r-75

6.5mm gauge, 145mm radius,45degree curved road/rail section with track on inside of curve. fits code 75 rail
Print off template

road-left-exch

road section for 6.5mm gauge, with track crossing from right hand side to left hand side of road. fits code 100 rail
road-left-exch-75

road section for 6.5mm gauge, with track crossing from right hand side to left hand side of road. fits code 75 rail
Print off template

road-right-exch

road/rail section for 6.5mm gauge, with track switching fro left to right side of road. fit code 100 rail
road-right-exch-75

road/rail section for 6.5mm gauge, with track switching fro left to right side of road. fit code 75 rail
Print off template

road-left-point

6.5mm gauge left point plus curve to start passing loop. use code 100 rail
road-left-point-75

6.5mm gauge left point plus curve to start passing loop. use code 75 rail
Print off template

road-right-point

6.5mm gauge right point plus curve to start passing loop. use code 100 rail
road-right-point-75

6.5mm gauge right point plus curve to start passing loop. use code 75 rail
Print off template

curve-tram-long-145r


145mm radius curved 6.5mm gauge track with plain surface. fit code 100 rail
curve-tram-long-145r-75


145mm radius curved 6.5mm gauge track with plain surface. fit code 75 rail
Print off template

straight-dbl-track-110

6.5mm gauge double track on road section, use code 100 rail
straight-dbl-track-110-75

6.5mm gauge double track on road section, use code 75 rail
Print off template

straight-long-110

110mm long straight 6.5mm track with plain surface. fits code 100 rail
straight-long-110-75

110mm long straight 6.5mm track with plain surface. fits code 75 rail
Print off template

straight-road-110

straight section of 6.5mm gauge track on 40mm wide roadway. fits code 100 rail
straight-road-110-75

straight section of 6.5mm gauge track on 40mm wide roadway. fits code 100 rail
Print off template

curve-road-only-145r

Plain road section
curve-road-only-145r-75

Plain road section to match code 75 track sections

straight-road-only-110

plain road straight
straight-road-only-110-75

plain road straight to match code 75 track sections
